HPE Aruba Networking R4W02A Wi‑Fi 6 Instant On Indoor Access Point AP22
R4W02A
- Wi-Fi 6 for high performance and efficiency
- Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3
- Standard Ultra-fast 802.11ax
- Ceiling/Wall-mount clip Compatible
- Supports up to 75 associated clients
- Instant On 2-year warranty with 24/7 phone support for first 90 days and chat support for the entire warranty period by HPE Malaysia
1 X HPE Networking Instant On Access Point
1 X Quick Start guide
1 X Combined ceiling and wall rail mount clip
1 X Ethernet cable
- Network / Connectivity Technology
- Maximum transmit power:
5 GHz band: +21 dBm (+18 dBm per chain, 3 dB MIMO gain)
2.4 GHz band: +20 dBm (+17 dBm per chain, 3 dB MIMO gain) - Interface
- 1 x GbE BaseT Uplink
DC Power Connector
Bluetooth
Low Energy (BLE) LED status Indicators
Reset/LED control button
Kensington security slot. - Battery / Power Supply
- Input voltagePower over Ethernet (PoE): 802.3af (class 3) DC power (12V)
Power consumptionMax power consumption: 10.1W (PoE), 8.8W (DC)
- Dimensions
- 37x 160 x 160 mm (1.5 x 6.3 x 6.3 in)
- Weight
- 500 g (1.1 lb)
- Antenna
- Down-tilt Dual Omni-directional 2x2 MIMO Wi-Fi antenna
Antenna Gain: 4.9 dBi in 2.4 GHz 5.7 dBi in. 5 GHz
